E-Simulator

Simulator Views

Click markers
⚠ 1
Rotor/Stator View
1500 RPM4Pf=50.0HzB=1.15T
U
V
W
Φ
🌡
η86%
PF1.00
Load63%
POWER189.3kW
LOSS30.3kW
TORQUE1205.0Nm
⚠ 1
Lateral View — Turbine to Terminals
1500 RPM4Pf=50.0HzB=1.15Tη=86%
Field:PM
Φ
🌡
η86%
PF1.00
Load63%
POWER189.3kW
LOSS30.3kW
TORQUE1205.0Nm
3-Phase Waveform (U / V / W)

Machine Controls

Speed
rpm
Excitation
V
Poles
ct
Turns
ct
Size
m
Load R
Ω
Field System:
1.15T

Live Output

Frequency
50.0Hz
Flux
225.8mWb
EMF
9.2kV
Line V
2.2kV
Current
50.2A
Power
189.3kW
Loss
30.3kW
Efficiency
86.2%
Core Temperature(25°C + Loss/100)
328°C
25°C150°C250°C350°C500°C
● Very hot — reduce load
T = 25°C + (3 × I² × Rw) / 100•Loss = 3 × I² × Rw
